Question 1

Can I scan exteriors with Twindo?

Accepted Answer

Yes, you can capture exteriors with Twindo! Please be aware of a few differences between scanning exteriors and interiors so that you understand what is possible, and you get the results you're looking for. Exteriors are available for converting to 3D models only. We are not able to generate 2D plans or elevations for exteriors. We do not recommend using Twindo for scanning landscaping, topography, and other natural, non-structural elements you may find outdoors. Our process will reject such scans unless they are part of a structure. Only structural elements will be modeled. We do not model landscaping, topography, fences, yards, driveways, sidewalks, etc. Estimation and Pricing As our in-app square-footage estimation algorithms were built for interior scans only, if your order contains exterior scans, the in-app estimation will likely be significantly off. Actual price is calculated from total floor area of each level, as measured from the exterior sides of walls. If the space is not closed, such as a single exterior wall, the square footage of the wall(s) will be used to calculate the area processed. Sunlight interference Bright sunlight is not as much of a factor as it used to be. While many 3D sensors can struggle to varying degrees in very bright, direct sunlight, the LiDAR sensor used in Twindo-compatible devices is less sensitive than older technology. However, it is still necessary to avoid shooting directly into the sun. Range The LiDAR sensor’s range is 5m or about 16'5", meaning roofs and second-story(+) exteriors will be very challenging to capture. So if you're standing on the ground scanning up the side of a house, you could capture about 20-22' okay, but accuracy will decline as you approach the maximum end of the the range, and beyond that will be out of range and not captured. Although this is a known limitation, we have many customers who find value in scanning exteriors, even if the entire exterior can't be captured. When capturing a multistory building, you'll move around the building, using the primary "fence-painting" method capturing as high as you're able. When you're done with your scan, get the height with your LDM. Then you can provide that height as a reference measurement when you place your order, ie. "Adjust the soffit to 30 ft," and then we'll manually adjust that dimension in your model. Check out this scan where the user did just that. He scanned the exterior of the home in two separate scans, then the interior in 6 scans. We merged them together into one global model of the space, and adjusted the model manually with the height dimension he provided. Drift on Large Scans Generally, the larger an area you cover in a scan, the more small, unnoticeable measurement errors can compound, which is why Twindo states an accuracy tolerance in relative percentage terms vs. absolute terms. If you are scanning a very large side of a home, you may experience more drift (or distortion) in your model, which can affect accuracy. Make sure to follow scanning best practices. CAD Oversimplification Our conversion pipeline was built and optimized for interior scans, which means that you may find some aspects of an exterior model oversimplified compared to the level of detail provided in our interior models. We do not convert landscape, fences, driveways, grass, or other items that may be important to your project. The model we deliver will be of the structure. Accuracy If the limitations above affect the accuracy or quality of your scan data, this can lead to inaccuracies in your model. This is unlikely to be significant, but may push you outside of our typical accuracy tolerances. If you have any questions, please contact support@twindo.com.

Question 2

Can I submit multiple scans of an entire home?

Accepted Answer

The Short Answer Absolutely! Twindo can convert your 3D scans into editable, design-ready, and professional-grade CAD files that can either be processed individually or merged into a single, global CAD model of the entire space. You can learn how big of a space you can scan at one time here: How big of a space can I scan? Tips for scanning a whole house with Twindo: Plan your scan Scan connecting areas Scan the small nooks and crannies Very large rooms/spaces may need multiple scans You will be asked if you would like to merge additional scans during checkout The Long Answer It is very common that our customers are not just scanning a single room or rooms, but a whole home and as such, they want one CAD file of all the rooms. We can merge your scans into a single, global file. When you are placing an order, you will be asked if you want to merge your scans. Selecting "yes" means you will receive a single, global CAD file. Otherwise, each scan will be processed individually. Merging is no additional cost and you will receive something like what you see below: This model took approximately 8 scans, and was captured in roughly 20 minutes. However, depending on the space being captured, you may be able to capture it in fewer scans, or even a single scan. You can learn more about the trade-offs here: How big of a space can I scan? Scanning a whole home We recommend starting with our scanning overview and tutorial. Plan your scan: Do a walkthrough of the home to open the doors between rooms, make sure the lights are on, and turn off ceiling fans (as the fans can distort light). This will ensure the best results and likelihood of a successful merge. Do not open or close doors, turn on/off lights, open window treatments, etc. during scanning as this can negatively affect the scan quality. Scan connecting areas: Make sure to scan through connecting areas like doorways to create a common point of reference. For example, when you scan the bedroom, scan a little bit into the hallway (and the other way around) so that it's clear how they connect. Just a few seconds of scanning the adjacent room is fine. Scan all intermediate areas: Make sure to cover all the intermediate areas between rooms that connect your scans. Sometimes first-time users forget to scan a hallway or entryway, and then you'll end up with two models of separate wings of the house instead of one. Scan small nooks and crannies: This is not strictly necessary, but it's generally a better, more complete model if you scan everything for a whole home model. Capture closets, hallways, and pantries, etc. because closet depth can have an impact on how multiple rooms fit together. It's not always vital, but in some houses, it can make a difference. Very large spaces: If you are scanning a really large, open space that is too big to fit in one scan, don't be afraid to break it into multiple scans. Make sure your start and end points between scans overlap so we have the connecting reference points to merge them together. You can see more homes we have scanned here. How do I place an order for a home? When you place an order you have the option to select "merge my scans". There's no added cost and selecting this option means we will provide a single global CAD model. Specific, step-by-step ordering instructions available here: Placing an order Can I merge interiors with exteriors? Yes! These models look great. Please be aware of these considerations regarding exteriors.

Question 3

Can I use a third-party 3D scanner with Twindo?

Accepted Answer

Twindo uses proprietary SLAM (Simultaneous Localization and Mapping) technology to recreate scale-accurate 3D models of real-world spaces via mobile devices. In order to do so, Twindo needs access to raw data captured by the device itself, and its algorithms need to be tuned tightly to that device. Twindo’s Scan To CAD pipeline is itself tuned to this output (and underlying raw data) in order to automate as much of the process as possible (and keep our prices lower than manual modeling/drafting). This makes supporting any third-party scanner a significant undertaking. As of right now, Scan To CAD supports only scans captured via the Twindo iOS apps Twindo: LiDAR 3D Measurements on a compatible device.

Question 4

Can Twindo scan a space that is still under construction or partially built?

Accepted Answer

The Short Answer Twindo was not optimized for this purpose, but we do have customers that use Twindo in partial construction projects. Our Scan To CAD files will include details such as beams, framing, doors, exposed walls, along with the other included details. Projects with completely open framing can pose a challenge for scanning and processing. We recommend breaking up these types of spaces into smaller scans and focus on scanning top to bottom. Because framing boards are thin enough to potentially cause issues, please consider sending actual framing dimensions as reference information after you've placed your order. In that case, we will override the scan data for the dimension you provide, which will increase accuracy. Here are some additional scanning tips. The Long Answer We've seen customers use Twindo in partially constructed space. Here is one such example: There are a handful of things to keep in mind when using Twindo to tackle this kind of space: Sunlight Interference If the walls are not fully built and exterior-facing, you may get a lot of very bright, direct sunlight coming into the space. This can interfere with the performance of most 3D sensors. Avoid shooting directly into the sun when possible. Messy Scans If the walls are just frames, Twindo will scan into the next room, which can create a messier looking scan because it's scanning past the frames as well. Break scans up into smaller chunks scanning from top to bottom. Difficulty Tracking When the walls are just frames, Twindo's ability to track may be impaired. "Tracking" is referring to how Twindo keeps track of your movement as you scan. If Twindo struggles to maintain tracking, you may see the scan "slip" or "jitter" which can reduce accuracy in the scan and the CAD file. If you see this happen while scanning, you will likely want to start over. Scan To CAD Oversimplification Some "partially built" elements of the room might get oversimplified in CAD format vs. the scan. For example, a concrete wall that has many small depressions from damage over the years may appear as just a normal flat wall, piping, or heavy electrical wiring may not show up in your CAD file. Additionally, if frames are similar but not identical in thickness, you may find that they are oversimplified to be the same, or that the count of frames is not 100% exact. Accuracy Any of these issues can cause accuracy to be slightly worse than our typical expected tolerances, which we outline here: What kind of accuracy can I expect from Twindo? All that being said, generally, the customers that we have worked with that use Twindo for scanning partially-built or under-construction spaces have been happy with the results. More often than not, the biggest issue is keeping other people at the construction site out of the room when you're scanning! Modeling as a finished space If you'd like us to create the model or CAD as if the space was finished with drywall, flooring, ceilings, etc. we would be happy to do this for you. Please simply make a note in the reference information requesting this.

Question 5

Does Twindo support AutoCAD?

Accepted Answer

Yes, you can order the 2D Floor Plan package which includes a 2D AutoCAD file (.dwg). Although Twindo's 3D packages include .dwg files, these are 3D models and are not optimized for use with AutoCAD. They do not contain 2D drawings whether it be floor plans, elevations, ceiling plans, or other types of 2D documents. AutoCAD LT is unable to work with these files. What does the 2D .dwg floor plan file include? The 2D .dwg floor plan file allows for full manipulation of the file in terms of editing the drawing or changing annotations. This file comes with pre-annotated dimensions for convenience, but you may turn these off or add different ones if desired from inside AutoCAD. You can download sample files here. Units and Scale Our AutoCAD files are delivered in inches by default. If you are importing your Twindo files into AutoCAD and intend to use any other unit besides inches (even if they are within the same system of measurement, e.g. feet), you will need to rescale the units based on their relative ratio to inches. Changing the unit type in AutoCAD alone will simply change the label, not the numbers. As an example, if you import with inches (default), 10 units is 10 inches. If you change the units in AutoCAD to architectural, or metric, 10 units is now 10 feet or 10 meters and the scale is way off. How to rescale AutoCAD unit from inches to different metrics The instructions below will guide you through rescaling units in AutoCAD from inches to different metric units using the SCALE command (you can find other methods for changing units in AutoCAD in this AutoDesk support article): In the command line, enter and select “SCALE" When asked to select objects, type “all” When prompted for basepoint (on cursor), enter “0”, then “,” then “0” to set the basepoint to 0,0 Next, specify the scale using the conversion listed below and in the linked AutoDesk article: Inches to Millimeters = 25.4 Millimeters to Inches = 0.0393701 Inches to Centimeters = 2.54 Centimeters to Inches = 0.393701 Feet to Millimeters = 304.8 Millimeters to Feet = 0.00328084 Feet to Centimeters = 30.48 Centimeters to Feet = 0.0328084 *Reminder: You can choose imperial or metric in your account settings before placing an order.

Question 6

How are the CAD models organized?

Accepted Answer

The Short Answer Scan To CAD files are delivered using professional-grade tagging, naming, and organization. Objects of the same type (e.g. walls, doors) will be grouped together on an appropriate layer or Tag. Software like Revit and Chief Architect will have default properties applied. Each file is fully editable allowing your to adjust to fit your workflow. We aim to organize the files to help you get the most out of your preferred CAD software, but we are not yet able to support custom templates, tagging, or naming. If you have any feedback, questions, or would like to learn more, please reach out to our support team at support@twindo.com. The Long Answer Tags (SketchUp) The number at the beginning of the named tag (e.g. 1_, 2_, 3_) will help group together items of similar stature. The number behind the name (e.g. L1, L2) will indicate what level the item is located on (first floor or second floor). Here's an example of a commonly tagged model that has two floor levels: Here is an example of disabling tags and how they can reveal/disable certain aspects: In the above image, the ceiling tag is enabled as visible; in the image below the ceiling tag is disabled (or not visible). Geometry Organization In our supported file formats, model geometry is organized so that you can work with key surfaces independently as if you had made it from scratch. This allows you to edit and manipulate the model using standard tools in that program: In Chief Architect and Revit, geometry is typically even more structured, in that walls are not just arbitrary geometry called "Wall," but an actual family or element. This is what allows for more advanced features like being able to generate construction drawings, generate cost estimates, etc. Revit and Chief Architect support in Twindo does support this added structure, but you may find that there are more fields that are empty, generic, or defaults. This is because we only have your scan data to work with, which does not capture things like wall thickness (which is assumed using construction standards) or material properties. Here are a few examples from Revit: We do aim to use best practices when organizing geometry so that it is easy to take advantage of the features people most in our supported programs, but every person's workflow is different, and we can't customize our model organization to individual workflows without very large commitments of volume. We are, however, very happy to hear your feedback and make changes that can benefit all users. For more information on how to use and manipulate tags within your CAD program, we encourage you to reach out to the customer support teams for the software you use directly (for example, AutoCAD or SketchUp)

Question 7

How big of a space can I scan?

Accepted Answer

The Short Answer There is no specific limit on how big of a space you can scan (except for the device memory), and you can scan room by room, several rooms at once or up to a whole floor. We recommend scanning each floor separately and stairways separately. Multiple scans can be converted into a single, global model, so how you break up the scans is flexible. More information on merging scans here. The Long Answer LiDAR-enabled iPads (which include Pro models 2020 and newer) and iPhone 12 Pro/Pro Max and newer will generally allow you to scan the largest areas at once, as the Twindo app allows you to walk around as you scan. In our testing, however, the RAM of the device will tend to max out at about one floor of a typical home, so large spaces will still require breaking up into multiple scans. However, it's really more about how long it takes to scan a space, and if you're able to do so using good technique. Try to keep any scans less than about 10 minutes long. Once you start approaching 10 minutes, it's a good idea to start looking for a place to end the scan so you can start a new one. Similarly, if you're unable to scan an entire floor without sticking to our Scanning Best Practices, it's a good idea to break the floor into more than one scan. As you take Twindo into larger commercial and industrial environments, you may run into different limitations, which you can learn more about here: I want to scan non-residential spaces. Will Twindo work outside the home? The three most important things are that you: Capture all sections of the home that you expect to show up in your CAD model somewhere in your individual scans Scan through connecting areas (like doorways) into the adjacent space (if you do intend to merge it with other scans) Avoid zig-zagging in and out of many rooms in a row within a single scan

Question 8

How can I generate my own 2D files from a 3D model?

Accepted Answer

If you already have a 3D CAD file, you can generate 2D floor plans yourself from your design program: SketchUp Open the .skp file in SketchUp. Using SketchUp's instructions here, use the slicing plane to slice through the model horizontally: https://help.sketchup.com/en/sketchup/slicing-model-peer-inside Go to Camera &#8211;> Standard Views &#8211;> Top Go to Camera &#8211;> check "Parallel Projection" instead of Perspective Go to Tools &#8211;> Dimensions, and then touch the points for which you want measurements displayed. Repeat until you have annotated all the important measurements. Take a screenshot or export as a 2D graphic. Revit Open the .rvt file in Revit Go to Project Browser and expand the Views tab Expand the Floor Plan section under Views Double click on the floor plan level you want to display Chief Architect Open the .plan file in Chief Architect. Position 2D plan the way you'd like to see it on the page Go to File &#8211;> Export &#8211;> Export Current View and save the drawing as a DWG 2020 DesignOpen the .kit file in 2020 Design. Position 2D plan the way you'd like to see it on the page. Go to File &#8211;> Export &#8211;> Other Formats &#8211;> save the drawing as a DWG For 2D Plan choose in "Shape Selection" dialog &#8211; "Floor plan shapes" AutoCAD 1. Open the .dwg file in AutoCAD. 2. Hit the top-down button in the top right corner. 3. Annotate the dimensions you need (there are multiple ways to do this in AutoCAD) 4. Go to File &#8211;> Export and save the drawing as a PDF. You can learn more about Scan To CAD's compatibility with various architecture and design programs in general here: What file formats and programs does Scan To CAD export?

Question 9

How can I get a receipt/invoice for an order?

Accepted Answer

You can view your full order history from the Projects view. Select “View orders only” to see your purchases. When you view your orders online, you can also download any associated files by clicking into the project. Click the “Orders” tab in the Project view to access the following information: &#8211; Order number is in the top left &#8211; “Get receipt” in the top right will open your invoice for downloading

Question 10

How do I apply a promo code?

Accepted Answer

Adding a Promo Code to your Order from the Twindo app Create an Order [How do I place an Order] On the cart screen, Expand the Add-Ons & Discounts Section Type Promo Code Tap Apply Code will be applied, code and discount can be removed Adding a Promo Code to your Order from Twindo.com Create an Order: Select the scans you wish to receive, then choose your format and proceed to the checkout screen [How do I place an Order] At Checkout: click "Add a Promo Code" Enter the code + Apply it to the order: Use the text box to enter your code, then click "Apply" The code is now applied to the order, and can be removed using the X button *Only one promo code can be used per order. Promo code cannot be applied retroactively; it must be applied when the order is placed. Anything under the code value is forfeited, i.e., we can't "give change." Promotions and Discounts are subject to change without notice. Please subscribe to Twindo.com emails for promotions.

Question 11

How do I get started with Twindo?

Accepted Answer

We're excited for you to start scanning! 3D scanning and spatial intelligence is a brand new frontier for most people, so we've created this Getting Started with Twindo guide to help! We highly recommend going through these steps before you go to your first project. This gives you time to test Twindo in your own home or office, read and practice scanning best practices so you get the best, most accurate results. You may have questions, and we can help you be prepared and feel comfortable before using Twindo on your first project. To help you get started, we are happy to review your scans and provide feedback. For more information about requesting a scan review, please see this guide. Step 1: Compatible Hardware You can find a list of compatible iPads and iPhones here. Step 2: Download Twindo: 3D LiDAR Measurements For all professional use cases, you will want a compatible LiDAR device and this app in order to get the best accuracy. Unfortunately, we do not support non-LiDAR devices. Step 3: Create a Twindo Account A Twindo account lets you place orders, download your files and models, download invoices/receipts, access our 3D Web Viewer and more. To avoid challenges later, please use your preferred work email. Step 4: Create a Project Scans are organized into folders called Projects. You can have multiple scans in each Project. As a free user, you can create up to two projects per month. For more, you’ll need to sign up for a membership. Step 5: Start Scanning The video below provides an overview of how to prepare and scan your home for optimal results. For additional videos and tips, visit scanning best practices and sign up for a live webinar or watch one on demand. We always recommend doing a trial scan in your home or office before using Twindo in the field. Reach out to hello@twindo.com with general questions, or to support@twindo.com if you have a question about an order or issues with using the Twindo app. Step 6: Order the format(s) you need Convert your scans into design-ready 2D and 3D files, in multiple formats, by placing an order. Before ordering a particular format, we recommend downloading and testing a sample file to make sure that the files we create are compatible with your software and will suit your needs. Note: You can order one, merged global file/model by including multiple scans from the same Project and selecting "Place as merge order." Step 7: Receive & Work With Your File Your file will be delivered directly to your business email address. Our typical timelines are noted here but please note these are estimates &#8211; not guarantees. If you need your order in a specific time frame &#8211; please email support@twindo.com for help. Once you’ve received your file, upload it into your software. The models will be layered, labeled and ready for you to just right into design. Step 8: Final Steps and More Help That's all! You're ready to conquer the world, one 3D scanned home at a time. If you have questions about how Twindo can be applied to your specific use case or have any other questions, just reach out to hello@twindo.com. Every space is different, so as you encounter new kinds of environments to capture, it's totally normal to have additional questions. As always, we're here to help!

Question 12

How do I place an order?

Accepted Answer

Twindo creates editable 2D and 3D CAD files, floor plans, and measurement reports from your scans. Using Twindo for as-builts saves significant time and money compared to modeling yourself or outsourcing. How do I place an order? Placing an Order from the iOS App Step 1: Select Your Project From the Projects screen, tap the thumbnail of your project (for example, "Green Street"). Step 2: Select Scans Tap each scan you wish to order. Choose whether you’d like the scans merged or processed individually and tap "Next” Step 3: Choose File Type Choose the file type you want to work in Click “Next” Step 4: Add Payment Method and Submit Add payment method, review, and confirm your order details. Hit “Place Order” Step 5: Add Reference Measurements (Optional) Submit any additional reference material or combine with a previous order in the same format from Order Details. Step 6: Model Creation That's it ~ we're on it! We'll deliver your file(s) soon so you can get to work! See estimated delivery times to learn more. For more information on what details are included and excluded in the models, check out this article: What details are included with my CAD file? And if you haven't already tested a sample file to make sure it is compatible with your software and will meet your needs, please download and test our sample files. Placing an Order from the Web Step 1: Start Order Process Click Scan To CAD Model from Nav Bar or + From Project View. If starting from Scan To CAD Model, you’ll next be prompted to specify which project you would like to order from. Step 2: Select Scans Click each scan you wish to order. Choose whether you’d like the scans merged or processed individually and tap Continue Step 3: Choose Format Choose the format you need Step 4: Add Payment Method and Submit Select the format(s) you need, then tap Next at the bottom. Add payment method, review, and confirm. Then, you'll confirm your order details. Step 5: Add Reference Measurements (Optional) Submit any additional reference material that can be used to improve the model accuracy. Step 6: Model Creation That's it ~ we're on it! We'll deliver your file(s) soon so you can get to work! See estimated delivery times to learn more. For more information on what details are included and excluded in the our models, check out this article: What details are included with my CAD file? And if you haven't already tested a sample file to make sure it is compatible with your software and will meet your needs, please download and test our sample files. Combining Orders To add new scans to a previous order (e.g., adding a 2nd floor to an existing 1st floor model): Order your new scans Tap Combine with Existing Model on the Order Details screen in the App within 8 hours. Add a note: "Combine this order with order #A1B2C3D4" (use your actual order number). You'll only be billed for the new square footage, not for areas we've already modeled. Important: Capture connecting spaces like stairs and hallways with doors open so we can see how the spaces connect. For more information, see our support articles on Scanning Best Practices, Adding Reference Materials, and Capturing Multiple Scans of an Entire Home. Questions? Contact us at support@twindo.com Plan To CAD Have plans you’d like to convert to 3D models? Log in to Twindo Web and click the “Plan to CAD Model” on the left side to order or request an estimate for your project. Upload your plans &#8211; must be a DWG, DXF, or PDF file Select your Format Add your estimated square footage Add your project details Provide rights approval on the plans you’ve uploaded. Click “Continue to Checkout” &#8211; you can also “Request an Estimate” for your order by clicking on the link below the checkout button. If you have any questions please don't hesitate to reach out to us at support@twindo.com. We strive to meet your expectations, so please let us know if you have any concerns!

Question 13

How do I scan a kitchen?

Accepted Answer

The video below outlines our recommended scanning methods for capturing a kitchen using Twindo:

Question 14

How do I scan a room with Twindo?

Accepted Answer

With Apple's LiDAR sensor, 3D scanning can be as easy as taking a video. The video below will outline our recommended scanning methods to help you get the best results each time. For additional videos and tips, visit scanning best practices. LiDAR iPad and iPhone Start in a corner of the room with a lot of details (book shelf, picture frames, patterns) Stand 5-10ft away, aim the iPad at the detailed corner and tap Scan to start (scanning with the device "sideways" in landscape orientation works best). Tip: Standing back can help Twindo keep better track of your position in the room. Move the iPad slowly up (or down) to the ceiling. You do not need to scan the entire ceiling or the entire floor. Take 1-2 steps to either side, and scan back down (or up) the wall to the floor As if you are spraying paint on the wall, continue with this pattern moving in one single direction Scan the perimeter walls until you are back at your starting point Tap Done to complete the scan Tips for best results: Avoid moving or pivoting without continuing the "fence painting" pattern Only scan up to one floor at a time, do not go up or down stairs Try not to capture anything more than once in a single scan In tight spaces like halls or stairways, try using the "J" scanning pattern shown in our scanning best practices

Question 15

How do I scan a staircase?

Accepted Answer

Capturing a staircase is a little bit different than capturing a typical room with Twindo, and we recommend a slightly different scanning technique than the standard "loop" pattern.

Question 16

How does Scan To CAD pricing work?

Accepted Answer

Twindo is free to download, scan, and measure. You'll be able to scan up two spaces per month at no cost, which captures all the dimensions of a space automatically, and the result can be seen here: So, what do I get after I'm done with my scan? This on-device result can be used to review, measure, and annotate, and the scan files can be exported at no additional cost with a Scale Plan membership or Scan to CAD order. A Real Game Changer for your Business Twindo can convert your scans into professional CAD files in multiple formats starting at $0.18/sqft. If you want to bring your 3D scan into architecture and design programs like SketchUp, AutoCAD, Revit, Chief Architect, Archicad, Vectorworks, 2020 Design Live, and more, you will likely want to use our built-in service which can be faster and less expensive than doing it yourself! We offer three types of memberships: Starter, our pay-as-you-go option. Starter members are limited to two projects per month. Essentials, for solo professionals to small teams, which allows for up to five projects per month, and offers a discount on our square-footage pricing. Scale, which requires an annual commitment but allows for unlimited projects, customized delivery timelines and outputs, a dedicated account manager, team accounts and our invite to scan feature. All orders are priced per square foot (or per square meter), and pricing for Essentials members starts at $0.14/sqft for 2D floor plans ($10 minimum/order) and $0.23/sqft for 3D models/reports ($20 minimum/order). How ordering, estimates and as-built pricing works When you place an order, you select the format(s) you need and the delivery type, and apply any discounts. The area of each scan is estimated, and you receive an estimated price range for the order. Your model, report, and/or floor plan is created. The actual square footage of the model is measured which determines the actual cost of the order. The order is delivered, and the payment method is charged. *Important notes* Our estimates are only estimates, and the price of your order will be calculated based on the actual square footage of the model and charged at delivery. The actual square footage is calculated from the total floor area of each level, as measured from the exterior sides of the walls. If a space is not closed, for example, if your order only contains a single wall, the square footage of the processed wall(s) will be used to calculate the cost. Our in-app square-footage estimation algorithms were built for interior scans, so if your order contains exterior scans, the in-app estimation will likely be significantly off. But remember, you are not charged the estimate, nor do you pay at ordering. You are charged the actual price at delivery. Estimates will include overlapping areas, but duplicated areas will only be charged once. If you have any questions about pricing in general or how the price for a particular order was calculated, please reach out to us at support@twindo.com, and we'd be happy to review your order. How to Place an Order Select your chosen format(s) Twindo produces professional CAD files for a variety of 3D and 2D software. We directly support SketchUp, Revit, Chief Architect, Archicad, Vectorworks, 2020 Design Live, and AutoCAD, but you can use our files with a variety of other programs as well. Please see more about formats here and download sample files to test for yourself. Starter Pricing 3D SketchUp, Revit, Chief Architect, Vectorworks = $0.26/sqft or $20 minimum per order 3D Archicad, 2020 Design Live = $0.29/sqft or $20 minimum per order 2D Twindo Measurement Report = = $0.29/sqft or $20 minimum per order 2D floor plans = $0.18/sqft or $10 minimum per order Essentials Member Pricing 3D SketchUp, Revit, Chief Architect, Vectorworks = $0.22/sqft or $20 minimum per order 3D Archicad, 2020 Design Live = $0.25/sqft or $20 minimum per order 2D Twindo Measurement Report = = $0.25/sqft or $20 minimum per order 2D floor plans = $0.14/sqft or $10 minimum per order Square Meter Pricing Go to account settings in the Twindo app or in your account portal, and change units to metric. Everything, including your delivered files and pricing, will be changed to metric for new orders, but invoices and order summaries for any past orders will not be changed. Starter Square Meter Pricing 3D SketchUp, Revit, Chief Architect, Vectorworks = $2.80/sqm or $20 minimum per order 3D Archicad, 2020 Design Live = $3.10/sqm or $20 minimum per order 2D Twindo Measurement Report = $3.10/sqm or $20 minimum per order 2D floor plans = $2.00/sqm or $10 minimum per order Essentials Member Square Meter Pricing 3D SketchUp, Revit, Chief Architect, Vectorworks = $2.40/sqm or $20 minimum per order 3D Archicad, 2020 Design Live = $2.70/sqm or $20 minimum per order 2D Twindo Measurement Report = $2.70/sqm or $20 minimum per order 2D floor plans = $1.50/sqm or $10 minimum per order Multi-Format Pricing If you order multiple formats, your price will be the sum of all formats ordered. For example, if you place an order for 1,000 square feet in both SketchUp and 2D floor plan, your total will be $440: $0.26 x 1,000 sqft for SketchUp ($260) + $0.18 x 1,000 sqft for 2D floor plan($180) Rush orders Rush delivery is available for an additional 20%. Rush delivery times are not guaranteed. While we always do our best to accommodate rush orders, please note that we can not always do so, especially for larger orders. The additional rush fee will not be charged if your order is not delivered within the rush timeline for any reason. More on delivery times.

Question 17

How is my scan data secured?

Accepted Answer

Twindo is most often used to capture personal and private spaces. Whether it’s your own home, a client’s home, or a secure commercial facility, we know that security and privacy are at the top of our customers’ mind. As such, we place the utmost importance on both security and transparency about how your data is handled. We have detailed answers to common questions below, but overall we follow three basic principles: Your data is never uploaded without an opt-in action. Your data is only ever “touched” when necessary to help serve you. Your data is your data. You may also be interested in reading our latest terms of service and privacy policy. Where is my data stored? All scan data is by default only stored on your device. If you do not explicitly choose to upload your scan data, it will never hit our servers in any way. Any uploaded data is transferred with secure HTTPS connections via our secure cloud infrastructure using modern encryption technologies. The data itself is stored on U.S. servers using Amazon Web Services (AWS), a leading provider of cloud infrastructure which itself applies its own additional encryption and security practices. How long is my data stored? We do not currently automatically delete data from our servers, so that customers can continue to retrieve data from old orders as well as add on to existing spaces. Abiding by the principle of “Your data is your data,” we are always happy to honor deletion requests for any uploaded data as well as GDPR forget-me requests, with the sole exception of orders opted into our Research Opt-In Program. If you would like to request the removal of any uploaded data, please reach out to support@twindo.com. Who can access my data and for what purposes? In short, absolutely no one at Twindo accesses customer scan data unless they are actively processing a Scan to CAD order, reviewing your order to provide technical support, or in aggregate to improve our products and services. If you have not uploaded your data, it is only on your device, never touches our servers, and there is no way for anyone to access your data. When scans are uploaded to our servers to store in your online account or to place a Scan To CAD order, a Twindo Web Viewer link (URL) is created for that scan. Link sharing is disabled by default and only visible to you. You can turn link sharing on and off. If you want to share the link with your collaborators, from the app or your account, tap the “Share” button, and enable Link Sharing. Then copy and share the link as you choose. Your collaborators will have access to your scan until you disable Link Sharing for that scan. If you place an order, there is human involvement in the processing of your data, as Scan To CAD is a semi-automated pipeline that includes a mix of both automated computer vision technology as well as human operators. The majority of the work is done by software to recreate your space and generate CAD geometry, with highly trained human operators using specialized tools overseeing the process — ensuring the files you get back are design-ready and professional-grade for your chosen file format. All Scan To CAD orders are processed by our dedicated team, who only have access to data for the duration and purpose of order processing under tightly controlled conditions. No details about your scans or orders will be shared with anybody outside your organization. If anybody (including yourself) reaches out from an email address that is not associated with your account, we will not share any information with them until we receive approval from an email address associated with your account either by directly matching that email address, or sharing a unique domain in the address. If you have any further questions to feel comfortable and confident in how your data is handled, please don’t hesitate to reach out to support@twindo.com.

Question 18

How long will it take to receive my order?

Accepted Answer

The time it takes to receive your order can vary based on several factors, especially the size of the space. Our delivery estimates are not guarantees, but these are our averages: Standard delivery Up to 1,000 sqft ~2 business days 1,001-2,000 sqft ~3 business days 2,001-3,000 sqft ~4 business days 3,001-4,000 sqft ~5 business days 4,001-5,000 sqft ~6 business days 5,001-8,000 sqft ~7 business days Above 8,000 sqft 7+ business days (Please contact Customer Success at support@twindo.com for a more precise estimate) Please note: Certain orders are more likely to vary from the above estimates, including larger spaces, more complex spaces, non-residential spaces and orders including exterior scans. Rush orders Rush delivery is available for an additional 20% Rush Fee. Rush delivery Up to 1,000 sqft ~1 business day 1,001-2,000 sqft ~2 business days 2,001-4,000 sqft ~3 business days Above 4,000 sqft We cannot guarantee expedited orders of spaces larger than 4000sqft Rush delivery is not guaranteed. While estimated rush delivery dates are not guaranteed, especially for larger orders, we always do our best to accommodate rush orders and they are prioritized in our queue. Your rush fee will not be charged if your order is not delivered within the rush timeline for any reason. Multi-Format Orders When you place a multi-format order (for example, Revit and SketchUp), the processing time will be the sum of all the formats you ordered. For example, if your scan is 750 square feet and you've ordered two formats, your estimated processing time will be four business days (2 days X 2 formats). If your scan is 1,500 square feet and you've ordered 3 formats, your order will be delivered in approximately 9 business days (3 days X 3 formats). When you rush a multi-format order, your turnaround time will also be multiplied by the number of formats you're ordering. For example, if you rush a 750 square foot order for two formats, your estimated delivery time will be 48 hours (and your rush fee will not be waived unless this time is exceeded). *What is a business day? Our business days are Monday through Friday, not including holidays. However, we do maintain some weekend and holiday capacity, so you may occasionally see orders delivered on weekends. Order delivery times are provided based on your local time zone, with a cut-off of 6pm. This means that if an order is submitted after 6pm in your device’s time zone, the estimated turnaround time will commence from the following business day at 8am. As an example, a 500 square foot order submitted at 4pm on Wednesday should generally be delivered on Friday (+2 days from Wednesday), but a 4,000 square foot order submitted at 9pm on Friday should generally be delivered on the following Friday (+4 days from the following Monday).

Question 19

How will I know if the Twindo files will work for my software?

Accepted Answer

Yes! You will find a few rooms and whole homes captured with Twindo and processed into all of our supported formats, as well as more information on each file type. Please review and download a sample file for your design software to verify compatibility and see how our files are made.

Question 20

I need a 2D floor plan. Do you produce these?

Accepted Answer

Yes! Twindo's 2D floor plans are $0.18/sqft and you'll receive an editable 2D AutoCAD file (.dwg) and editable 2D Revit file (.rvt), and a PDF file with annotated dimensions, which is easy to open and share. Please note: These are all 2D files. These 2D files are only floor plans; they do not include 2D elevations. 2D floor plan orders do not include any 3D information, and 3D outputs do not include a 2D floor plan. If you would like to receive both a 3D model and a 2D floor plan, please choose both formats during ordering. 2D files are not available to order for exteriors. We follow the US architectural standard of setting a "cut plane" at 48" above the finish floor when drafting 2D orders. This means that any details above the 48" cut plane will not be included. However, we are able to include high windows above this cut plane upon request. To request this when placing your order, please use the "Add Additional Information" button which appears after your order has been placed to add a note saying: "please include any high windows over 48 inches." You can also create 2D floor plans from Twindo's 3D files if you work in these 3D software design programs, or from the 3D scan (.obj) itself. Example PDF result delivered in as little as one business day: You can download sample 2D PDFs and CAD files and test them for yourself. Generating your own 2D files If you already have a 3D CAD file, you can generate 2D floor plans yourself from your design program. See this guide on how to generate your own files. You can learn more about Scan To CAD's compatibility with various architecture and design programs in general here: What file formats and programs does Scan To CAD export?

Question 21

I need higher accuracy than 1-2%. Can I submit my own dimensions to improve accuracy?

Accepted Answer

The Short Answer On its own, using Twindo with a LiDAR-enabled device will yield accuracy tolerances of within 1-2% of manually verified dimensions. This is largely a function of the devices themselves, and you can read more about expected tolerances here: What kind of accuracy can I expect from Twindo? If you require a higher degree of accuracy for specific critical dimensions, you may always send in manually-verified field measurements to accompany your order. This will "override" the scan for the measurements provided (where possible), and use the scan data for the rest. You may submit reference dimensions/materials either in the app or through the web portal using the "Add Additional Information" button which appears after your order has been placed. Wait until your order has fully uploaded, then submit the information as soon as possible: within 8 hours for a standard job or within 2 hours for a rush job. The Long Answer Reference Material Accuracy Please note that when measurements are provided for incorporation into your order, we rely fully on both the accuracy of your measurements and the readability of your reference material. If the measurements provided are themselves inaccurate, or it's unclear what they refer to, this can lead to inaccuracies in your files or additional questions and revisions which delay your order. While we always will make our best effort to bridge the gap with you, we can not guarantee that all dimensions will precisely match. In the rare case that reference material varies significantly from the scan, we will be unable to override the data from the scan without risking introducing significantly larger errors. This threshold is 6" for measurements under 300", and 12" for measurements above 300". Scaling The dimensions you provide are not used to "scale" the rest of the model, and are instead solely used to override that particular measurement from the scan. Error in 3D scanning is not uniform, so scaling all dimensions according to a single or few reference dimensions will not always make other dimensions more accurate. However, providing reference dimensions does have the effect of controlling error during the process and producing a more accurate overall model. Guidelines For Submitting Manual Measurements You may submit text notes, a photo or a drawing with manual measurements. For a drawing, please follow these guidelines: Your verified dimensions must be annotated in clear and legible text or handwriting, using English characters. Imperial or metric units are both acceptable; please denote which you are using. The start and endpoint for any dimension must be clear and unambiguous from the drawing, and not rely on "industry-standard" assumptions (e.g., does a door opening dimension include the casing around it or not &#8211; these vary significantly across industries). Send your drawing as an image or PDF — if you send another file type, it may not be accepted or it may require additional time to triage. A digital drawing is preferred, but a photo of a hand drawing is also acceptable if the photo is clear and readable. Here is an example of a totally acceptable drawing submitted by a customer with their order as extra reference:

Question 22

I want to scan non-residential environments. Will Twindo work outside of the home?

Accepted Answer

The Short Answer Twindo was purpose-built and optimized for scanning residential environments. We've seen many customers use it successfully and regularly across all kinds of spaces (including residential, retail, commercial, industrial, and even archaeological!), but you may run into certain limitations using Twindo outside of its intended purpose. It’s important to note that there is nothing within the app that will prevent you from scanning non-residential spaces and requesting their conversion into CAD files via Scan To CAD. However, we recommend reading this FAQ in full to set your expectations appropriately and approaching your use case with an experimental spirit, as there may be a few aspects of using Twindo that require more attention or workarounds. We are unfortunately unable to model or draft any portion of any type of vehicle, interior or exterior. As always, if you have any questions about using Twindo for a particular project or industry, simply send us an email at support@twindo.com. The Long Answer Using Twindo to scan non-residential buildings is very possible, and we see it all the time. However, depending on your use case, you may run into some limitations. Here are a few known limitations that we've encountered. Scanning range Apple's LiDAR sensor has a range of 5m (15ft). Given that you can walk around a space as you scan, these range limits are generally only an issue when capturing certain elements or environments like: Tall ceilings (e.g. warehouses) and any relevant details on or near them (windows, beams, etc) Tall structures or equipment (e.g. tanks) These circumstances don’t happen often in a home, but in commercial and industrial environments, they are more common. Size Across the case studies we've run with professionals out in the field — using Twindo and Scan To CAD on real-world projects — we see that most measurements in the final CAD file generated are within 1-2% of what's verified manually by tape measure, laser range-finder, or existing blueprint. You can read more about Twindo and accuracy here. In a very large commercial or industrial space, that relative error can add up to much larger absolute errors. It can also require more scans, which can be more error-prone to merge together depending on the available reference. Of course, these challenges (cost and accuracy) are present when measuring large spaces the old fashion way as well! Highly reflective, transparent, or dark surfaces Such surfaces can cause issues with most kinds of 3D sensors. In a home, this typically is limited to things like bathroom mirrors and reflective kitchen appliances, but it's easy to scan around them (or they’re small enough that they have a negligible impact). In commercial and industrial environments, there may be more transparent, metallic, or reflective objects, and you may find the model "slips" more while scanning or creates errors in the scan. Lighting Twindo works best when there are lots of “features” in the scene — fixtures, windows, doors, patterns, etc. This is why Twindo can struggle if you get too close to a wall: the only thing it sees is blank white for many frames in a row during your scan, and it loses track of where you are. Low or no lighting can have a similar effect in that these details are difficult to discern, and Twindo has trouble maintaining tracking of where you are in the scan you’re creating. In many industrial environments, adequate lighting can be a challenge. If you plan on scanning in dark environments, we recommend setting up a few lights to help illuminate the space and avoid moving shadows. CAD over-simplification Scan To CAD is highly optimized for residential environments, so you may find equipment or features only common in commercial or industrial spaces are over-simplified or missed entirely. Subtle details such as a control panel’s knobs and switches will likely not be included, but as a general layout of what’s in the scene and where, Scan To CAD usually provides more than enough information. A common question we receive is if Twindo and Scan To CAD can capture and process piping or conveyor belts. Twindo does capture this information in the scan, but they are often missed or simplified (beyond the level needed for commercial or industrial applications) by our standard Scan To CAD pipeline and require extra human effort and/or be less precise. Further, they can often be difficult to scan properly because it can be difficult to follow our recommended scanning techniques with lots of equipment or pipes in the way. Vehicles, etc. Twindo is purpose-built for residential interiors and not for vehicles, boats, RV's, or similar objects. In the past, we have attempted to convert these types of spaces for convenience, but ultimately, we've found there is oversimplification and the resulting CAD files do not convey the nuanced details or curves that are expected. These conversions are also often very dependent on manual modeling which Scan To CAD is not priced for. As such, we no longer convert these objects to CAD and the scans will be rejected from our Scan To CAD process. However, you can certainly scan vehicles, and more, with Twindo. The scan can be viewed, measured and shared, and you can export it as an .OBJ file- all at no cost.

Question 23

I want to talk to a human! How do I call you?

Accepted Answer

General Questions We are regularly available for scheduled calls to help answer your questions about Twindo and discuss how 3D scanning may make your workflow more efficient. For more information, please join our regular live Webinar. Most answers can be found in this FAQ or through product demos, webinars and events, but of course, we are happy to speak with you as well! Technical and Order Support We're ready to help! Please email support@twindo.com with any order-specific questions or issues. Please provide details in your email so that we can quickly route your problem to the correct person for assistance. Why can't I find a phone number on your website? We understand! Unfortunately, we serve customers all around the world, and the cost of operating a call center across so many different geographies would mean we'd have to charge much more for our products and services. We aim to get back to every message as quickly as possible. Please reach out to the relevant email address (Sales/Hello or Support), which is the best way to ensure a fast reply.

Question 24

I would like to deploy Twindo across my entire company. Can you work with larger organizations?

Accepted Answer

Yes! We've already seen Twindo deployed in large companies looking to power their sales or professional services groups (as well as create totally new offerings). If your business has something to do with residential, light commercial, or multi-family buildings, we've probably talked to someone looking to leverage Twindo for a similar use case &#8211; we're more than happy to share our feedback about what has worked most successfully. If you are interested in larger deployments, please contact hello@twindo.com with a brief description of your business, the use case for Twindo, and your goals.

Question 25

Is my scan done uploading? It looks stuck.

Accepted Answer

Most scans have no trouble uploading and the vast majority should complete within 20 minutes. In some cases, however, they get stuck. If it has been more than 24 hours since you started your upload, we first recommend force quitting Twindo, restarting your device, then re-opening the Twindo app. This usually does the trick for uploads that get "stuck", but if the upload does not resume and finish within 2 hours, let us know at support@twindo.com so we can help you resolve the issue. Again, it's important to keep the Twindo app open and connected to wi-fi to allow the upload to complete.

Question 26

What can I do with my Twindo Account?

Accepted Answer

A Twindo account gives professionals and their teams a fast, accurate way to understand the spaces they design, build, and manage, without extra site visits or second-guessing. With a simple scan or upload, any space becomes structured, accurate, design-ready data in the formats you need: a digital twin that captures existing building conditions and lets your whole team understand the space like they’re standing inside it. Learn more about setting up and using your account below: Creating an Account & Logging In Managing Projects Ordering Models Plan to CAD Twindo Viewer Order History & Downloading Invoices Contact and Payment Information Units Creating an account & Logging In To create an account at Twindo.com: Open https://app.twindo.com/signup on your web browser or visit Twindo.com and click “Get Started” in the top right corner. Enter your work email and an 8 character password and then click “Create Account.” Please take note of your account information so you can log in with it again. You’ll then need to answer a few more set up questions &#8211; this helps us customize your Twindo experience. That’s it! Your account is ready. To return to it &#8211; head to twindo.com and click “Account” in the top menu to log in. Use the email / password you chose during your initial set up &#8211; using different information won’t allow you to see your projects. NOTE: To reset your password, click "Forgot Password" and enter your account email REMINDER Twindo pairs simple, accessible capture with our iOS app and our best in class web experience to give you a unified workspace to view, organize, and collaborate on spatial data. In order for this to work you must log in to both our Twindo App and Twindo Web using the same account in order for the devices to properly share data. Managing Projects When you first log in to Twindo Web, you’ll see your Project list. Click the plus button to add a new project &#8211; just add a name. You can also use our “Invite to Capture” feature to invite collaborators to scan a space for you or work on a project with you. Simply add their email addresses to invite them. (Don’t worry &#8211; only you will see your billing information.) This means you can have one person out scanning in the field and uploading scans, and a different person ordering them later. It also means you could scan all the rooms in a home, upload everything for safekeeping and using our 3D Web Viewer, and then selectively order the rooms you need for that project later. Now you’re ready to add scans to your Project. Open your Twindo App using the same log in information (or ask your collaborator to scan the space). Once you’ve captured the space &#8211; click the upload button for your scans to appear here. Ordering Models Your Twindo Account Portal also allows you to place orders online for uploaded scans or to upload and order from 2D plans (Plan to CAD). Order Models from Scans Log in to your account Under “ORDER MODELS” on the left hand menu, click “Scan to CAD Model” Select your project If you have more than one scan you’d like to include in your order, select each of them. Then indicate if you want them delivered in a single model or separate models. Then click “Continue to formats” in the bottom right. Note: if you’d like the scans to be merged together into a single model select “Yes, Merge Scans” from the next dialogue box. Choose the format you need and click “Continue to Checkout” Review order details and options Processing Priority: Choose Standard or Rush Delivery. Rush processing is an additional 20% which is only charged if the rush delivery time is met. More info here. Estimated delivery date. Many orders can be processed within 2 days, but processing time can be affected by order size and complexity. More information here. Select/enter payment method and place order (Optional) On the confirmation page &#8211; you can submit any additional reference material that can be used to improve the model accuracy. We must receive these reference measurements within 8 hours of order submission for them to be used. Plan To CAD Have plans you’d like to convert to 3D models? Click the “Plan to CAD Model” on the left side to order or request an estimate for your project. Upload your plans &#8211; must be a DWG, DXF, or PDF file Select your Format Add your estimated square footage Add your project details Provide rights approval on the plans you’ve uploaded. Click “Continue to Checkout” &#8211; you can also “Request an Estimate” for your order by clicking on the link below the checkout button. Review your order details, add a payment method and click “Place Order” Twindo Viewer Log into your account Your Projects will load automatically Search for the order using scan name, project name, order ID, etc. Open the project On the right, click the “Open in Viewer” linkClick on the thumbnail and the Web Viewer will open! You can pull initial measurements and view the space immediately. Learn more about using the Web Viewer here Order History & Downloading Invoices With a Twindo account, you can view your full order history from the Projects view. Select “View orders only” to see your purchases. When you view your orders online, you can also download any associated files by clicking into the project. Click the “Orders” tab in the Project view to access the following information: &#8211; Order number is in the top left &#8211; “Get receipt” in the top right will open your invoice for downloading &#8211; “Download Files” will create a zip file for download (it will download automatically) &#8211; Click open the “Specifications” drop down to see other details about this order Note: If there is any information you need about your orders, just contact us at support@twindo.com, and we’ll do what we can to help. You can also use your order history to see estimated and completed delivery dates for orders, as well as download invoices. You can learn more about retrieving invoices here. Contact and Payment Information With your Twindo account, all of your payment details, contact information, membership settings, and preferences are synced across between devices and Twindo web. To access, change, or edit these details through Twindo Web: Log in and click your initial in the top right Your Account view will open To change payment details click “Payment Method” (you can add multiple cards and select a default) To change your account details (i.e. name, account email, or delivery email, which is optional) click “Edit Profile" See below for changing membership or units Now, anytime you log in to a new device, you won’t have to reenter your account details (especially emails and credit card information). Please note that the default payment method will be the payment method for all devices and users of that account, and all payment methods will be available to all users of the account. Units Changing units will change the display of units across the Twindo app and your Scan To CAD results. You can learn more about changing units here. If there is any information you need to be included or changed, just contact us at support@twindo.com, and we’ll do what we can to help.

Question 27

What details are included with my CAD file?

Accepted Answer

Twindo processes your 3D scan data into scale-accurate, simplified geometry that's easy to use in various CAD programs like SketchUp, Revit, Chief Architect, Archicad, Vectorworks, 2020 Design Live, AutoCAD and more. The intent is to provide a "blank slate" of the space with a reasonable level of detail for design, quoting, and documentation. This means we not only try to include the basics like walls, doors, and windows, but also baseboards, crown molding, light switches, ceiling lights, and other details that are both built-in and affect the utilization of the space. Some built-in detail such as fireplaces may be simplified due to the nature of our conversion process. This especially applies when using Twindo in non-residential spaces. Any “movable” furniture (e.g. chairs, tables, TV’s&#8230;etc) will not be included in your model. However, the dimensional information will still be in your scan, so you can always revisit the scan when needed in-app or via the Twindo Web Viewer. For those familiar with BIM level of detail standards, our output is targeted at a AIA LOD 200. *** Please note that details differ between the various software programs we support. Download and test our sample files in your design program to ensure compatibility and see the details you can expect. The Long Answer There are some differences between the features included with 2D plans and 3D files as noted below: 3D files (interior details) Walls Doors and door casing HVAC vents* Windows and window casing* Crown molding, baseboards, trim (interior) Ceiling details (e.g. vaulted, exposed beams, coffers)* Ceiling lighting* Beams, columns, kitchen islands Cabinets, countertops, and other casework Major and/or built-in appliances (e.g. toilets) Staircases and railing Fireplaces Electrical outlets and light switches 2D floor plans Annotated dimensions for key elements (you can download a sample 2D floor plan here). Walls Windows* that begin below 48" from floor (not including casing) Doors (measured as the opening only, not including casing, and inclusive of door direction) Floor-mounted casework (e.g., countertops) Floor-mounted major and/or built-in appliances Steps with direction Columns and kitchen islands For any included detail, we are using standardized geometry and components, meaning that these details will not always match exact detail. *May be difficult to scan completely or discern from a scan in certain scenarios (i.e., the window is covered by blinds), and occasionally assumptions have to be made. In general, we can only process what can be seen clearly in the scan. It’s important to us that you’re happy and satisfied with your model, so we will also cover details that are not included (we want to prevent any surprises!). Not Included Ceiling fans Furniture Fixtures that are not permanently attached to the framing of the building— for example, many organization solutions are custom built for a specific closet, but they are not permanently built-in to the structure of the building. These would be omitted. A good rule of thumb is that if demolition of the existing building or facade would not be required to remove it, it's not considered permanent. Fixtures that are movable. For example, entertainment centers, desks, or bookshelves would not be included. Notes you made on your scan in Twindo Curtains Details inside walls like frames (unless exposed — Twindo cannot scan through walls!) 2D plans will not include outlets or objects (such as windows and wall-mounted furniture) more than 48" above the floor Note there are differences between the various software programs we support. Test our sample files for more information. Equipment, Piping, etc. Twindo was built for residential projects, but commercial and industrial spaces can also be processed with some caveats. In non-residential spaces, customers often ask about equipment, piping, and other features that are not common in homes. Although not guaranteed (as the list of included details above is), as a rule, we try to over-include vs. under-include. Our system will generally pick up anything that it perceives as "built-in" and structural — regardless of whether it's a residential item or not. So items like piping may or may not be included in a simplified, proxy form. You can learn more at: I want to scan non-residential environments. Will Twindo work outside of the home? Ornate, Complex, and Organic Shapes In some cases, organic shapes or extremely ornate or non-traditional components of a room may get simplified due to the nature of the conversion process. In these cases, your colorized scan may be useful as it will preserve all the detail that was scanned. Converting this detail into CAD format would be extremely manual, and we would have to charge a lot more to convert this more photo-realistically. If you have a custom scale plan with us, there may be objects that fall outside of our standard included details, or higher level of detail available to you. This will have been specifically discussed when you set up your custom plan with your account rep. Please reach out to your rep with any questions. As always, feel encouraged to reach out to hello@twindo.com for questions about your intended use of Twindo or to support@twindo.com regarding an orders.

Question 28

What device should I use with Twindo?

Accepted Answer

To be able to use Twindo&#8217;s Scan to CAD feature, you&#8217;ll need an iOS device with built-in LiDAR. You&#8217;ll find it in these models: iPhone 18 Pro: Starts at $1199 &#8211; current model, released September 2026 iPhone 18 Pro Max: Starts at $1299 &#8211; current model, released September 2026 iPhone 17 Pro: Released 2025 iPhone 17 Pro Max: Released 2025 iPhone 16 Pro: Released 2024 iPhone 16 Pro Max: Released 2024 iPhone 15 Pro: Released 2023 iPhone 15 Pro Max: Released 2023 iPhone 14 Pro: Released 2022 iPhone 14 Pro Max: Released 2022 iPhone 13 Pro: Released 2021 iPhone 13 Pro Max: Released 2021 iPhone 12 Pro: Released 2020 iPhone 12 Pro Max: Released 2020 13-inch iPad Pro (M5 chip): Starts at $1,499 — current model, released Oct 2025 11-inch iPad Pro (M5 chip): Starts at $1,199 — current model, released Oct 2025 13-inch iPad Pro (M4 chip): Released 2024 11-inch iPad Pro (M4 chip): Released 2024 12.9-inch iPad Pro (6th Generation): Released 2022 11-inch iPad Pro (4th Generation): Released 2022 12.9-inch iPad Pro (5th Generation): Released 2021 11-inch iPad Pro (3rd Generation): Released 2021 12.9-inch iPad Pro (4th Generation): Released 2020 11-inch iPad Pro (2nd Generation): Released 2020 What about the iPhone Duo? The iPhone Duo does not have a LiDAR sensor, which makes it incompatible with Twindo&#8217;s scanning technology. iPhone or iPad? It&#8217;s really a matter of personal choice, as there&#8217;s no discernible differences between the scans from these devices. The iPhones are good choices for those who don&#8217;t want to carry an additional device. The iPad is a good choice if you want a bigger screen or more than one person will be scanning. Depending on your phone plan, and if you&#8217;re due for an upgrade, the iPhone may or may not be less expensive than the iPad. WiFi vs. Cell You do not need to be connected to the internet to scan; you only need to connect when you&#8217;re ready to upload scans/place orders. So, WiFi vs. cell is completely up to you and your workflow! Storage Storage refers to the amount of data your device can hold at one time. When using Twindo, it affects the number of scans or homes you can hold on the device at one time. The base storage capacity for most of these devices is 128GB which is more than enough storage for Twindo, but a higher capacity may be necessary depending on what else you store on the device. Generally speaking, this is very rarely a practical concern for our customers, unless you use the device to store a lot of videos or audio files in addition to scans. While the total storage footprint for a home can range given the size of the home, in our experience, the average typically ranges from 500MB to 1GB, with exceptionally large homes and projects taking up to 5 GB of space. On a 128GB device with ~60GB free, someone could still hold many homes before needing to free up space. On a 256GB or larger device, storage should effectively stop being a practical consideration. If you regularly capture large multi-floor or commercial properties, uploading scans as you go rather than accumulating them on-device is the simplest way to keep space free. What about non-LiDAR iPhones or Android? Twindo is currently only compatible with iOS devices, and specifically the LiDAR-enabled devices listed above. If you would like to be notified if support for other devices becomes available, please sign up for our newsletter. Some of our customers who don&#8217;t already have a compatible device, will buy one just to use Twindo for measuring and digitizing a space. Using Twindo as a business tool usually pays for the device in one or two jobs. The resulting CAD files from our service can be imported into your design programs which can be running on Windows. Find Your Model To identify which iPad or iPhone you have: Open &#8220;Settings&#8221; Tap &#8220;General&#8221; Then tap &#8220;About&#8221; Find the &#8220;Model Name&#8221;

Question 29

What do I get from colorizing my scan?

Accepted Answer

The Short Answer Twindo: LiDAR 3D Measurements now Colorizes your scan directly on your device! However, for additional processing on our more powerful servers you may upload your scan and access it via the Web Portal. Within the portal you can place orders or access the 3D Web Viewer which lets you view, measure, and share your scans. You can read more about how to use the 3D Web viewer here: What is the Twindo Web Viewer and how do I use it? The Long Answer While scanning, Twindo creates a scale-accurate 3D model of the space. Once you finish, the scan will process into a 3D model you can measure and view, annotate, and share with others. After Colorizing You can view an example of an uploaded Colorized scan interactively by accessing the 3D Web Viewer with this example: You can read more about how to use the 3D Web viewer here: What is the Twindo Web Viewer and how do I use it?

Question 30

What does all of this cost?

Accepted Answer

It's free to use Twindo to scan and measure up to two projects per month, but there are two other costs to consider based on your needs and desired outcome: iPad or iPhone with LiDAR Twindo as-builts Twindo app The Twindo app is free to download. Once you have the app, you'll be able to scan two spaces at no cost. This on-device result can be used to review, measure, and annotate, and the files can be exported at no cost. However, if you want to bring your 3D scan into architecture and design programs like SketchUp, AutoCAD, Revit, Chief Architect, Archicad, Vectorworks, 2020 Design, etc., you will likely want to use Twindo's as-built service which converts your scan into a professional, editable 3D CAD/BIM model, a 2D floor plan, or a Twindo Measurement Report. iPad or iPhone To achieve the best results with Twindo, you'll need a LiDAR-enabled iPad Pro (starting at $799) or iPhone (starting at $999), which can be purchased from Apple or any authorized Apple reseller. You can read more about which scanning hardware to use here: Which device should I use with Canvas? Twindo As-builts Twindo transforms your scans into editable, professional-grade CAD formats. Twindo directly supports the most popular design software so you don't have to create the as-builts yourself. You get to jump straight to the fun part: design! We directly support SketchUp, Revit, Chief Architect, 2020 Design Live, Archicad, Vectorworks and AutoCAD. Pricing starts at $0.14/sqft for 2D and $.26/sqft for 3D for our Essential members. You can find more detailed pricing information here: Pricing

Question 31

What file formats and programs does Twindo support?

Accepted Answer

Twindo produces professional CAD/BIM files for a variety of 3D and 2D software. Twindo directly supports the following programs, which means our files are fully compatible and editable. SketchUp, Version 2023 Includes file types: 3D .skp, 3D .dwg, and 3D .dae Your .skp file will open in SketchUp version 2021 and later, design-ready, with all the groupings, layers, etc. that you would expect as if you made it yourself. Using Twindo with SketchUp is very plug-and-play. If your version of SketchUp is 2020 or older, we’re happy to deliver your file in the version you need by request. Follow these directions on every order: Right after placing your order, tap “Add Additional Information.” Write “SketchUp XXXX” with XXXX representing the year of your SketchUp version and submit. Revit, Version 2023 Includes file types: 3D .rvt, 3D .dwg, and 3D .ifc Your .rvt file will open right in Revit, design-ready, in the correct families, and overall function as if you made it yourself. For Revit users incorporating Twindo into a BIM workflow, our Revit output is targeted at an LOD 200 specification. Revit files cannot be "saved down" to an older version. Chief Architect Premier, Version X15 Your .plan file will open right in Chief Architect Premier, design-ready, with geometry in the correct elements as if you made it yourself (i.e., doors are doors, walls are walls, etc). Please see below for more information about Home Designer or Chief Architect Interiors Chief Architect files cannot be "saved down" to an older version. 2020 Design Live, Version 13 Your .kit file will open right up in 2020 Design Live, design-ready, and organized as if you built it from scratch. 2020 Design Live is not backward compatible so our files will not work on earlier versions of this software. Archicad, Version 28 Your .pln file will open right up in Archicad, design-ready, and organized as if you built it from scratch. Archicad has local versions with their own local object libraries and settings that match local building codes. Twindo creates as-builts in the following versions, which you can select when placing your order: USA International Other, which will include a .pla template file with all International library objects Vectorworks, version 24 You’ll receive a native, professional-grade Vectorworks file with objects in the correct classes and layers, as if you made it yourself. We can deliver your file in earlier versions by request. We can back-save to version 19. Follow these directions on every order: Right after placing your order, tap “Add Additional Information.” Write “Vectorworks XXXX” with XXXX representing the year of your Vectorworks version and submit. Twindo Measurement Report Delivered files: 2D floor plan in .pdf only, data table of object quantities and key dimensions including a few vertical dimensions in both .pdf and .xlsx. We convert interior scans only for this format; no exteriors. 2D Drawings (PDF and AutoCAD) Versions: AutoCAD 2013; PDF files will be compatible with any PDF reader; RVT files in Revit 2021 version. Your 2D .dwg file will open in AutoCAD, design-ready and editable. We also include a PDF with annotated dimensions, which can be easily shared with anyone without special CAD software, as it can be opened by the native PDF reader that comes pre-installed on most smartphones, tablets, and computers. We convert interior scans only for this format; no exteriors. Note: AutoCAD files are delivered in inches, so you may want to re-scale the model you receive depending on your preferences. Information on converting units in AutoCAD here. You can download sample files to experiment with real, Twindo-generated CAD models for yourself! Complete pricing information. Indirectly Supported The files delivered in our package– both the native files and the additional formats including IFC, DWG and DAE– can be imported into any software that supports them and be used either as references or as partially editable models (depending on the software). However, there are known limitations with indirectly supported formats. Please read below for important information on the most common file types we hear and make sure to test our sample files before ordering. Home Designer Pro Home Designer Pro is a slimmed down offering from Chief Architect, and differs from Chief Architect Premier which is fully supported. Many of our customers use Twindo for Home Designer Pro seamlessly and successfully! When you place an order, it is important that you use the "Add Additional Information" button that appears after an order is placed to send this message to our team: "Please optimize for Home Designer." This reference submission button is in the app and your online account portal. Please submit this message within 8 hours for a standard order and within 2 hours for a rush order. Please test our sample files and test it before ordering, and let us know if you have any issues. AutoCAD LT We have not thoroughly tested AutoCAD LT, but we have validated the 2D .dwg file from our 2D Floor Plan output with AutoCAD users. We are unaware of any issues using the 2D .dwg file from the 2D Floor Plan output with AutoCAD LT. 3D .dwg files generated from other outputs, however, may not work well with AutoCAD LT as the product is not optimized for 3D use. Please test our sample files and test it before ordering. AutoCAD Architecture We have not thoroughly tested AutoCAD Architecture, but we have validated the 2D .dwg file from our 2D Floor Plan output with AutoCAD users. We are unaware of any issues using the 2D .dwg file from the 2D Floor Plan output with AutoCAD Architecture. We have heard of some customers using the 3D .dwg (from the Revit package) with AutoCAD Architecture, but we recommend validating this workflow yourself by test our sample files.

Question 32

What is Invite to Capture and how do I use it?

Accepted Answer

Invite to Capture lets you invite clients, homeowners, subcontractors, and field teams to capture spaces for you. Capture more projects with less effort while keeping all your data organized in your Twindo account. After accepting a project invitation, collaborators can capture and upload to shared projects. Once uploaded, their scans and project assets become instantly accessible in your account for review and ordering. Key benefits: Lower operational costs by reducing travel time, onsite labor, and scheduling delays Greater scalability to capture more projects per month with the same team Secure access control to projects How do I invite collaborators to a project? Log in to your account and open your projects view at: https://app.twindo.com/projects. When creating a new project: Name the project Add collaborator email addresses during project creation Click “Send Invite” to save them into the Project Click Create to send invitations For existing projects: Open the project Click the “&#8230;” in the top right to open Project Info Add collaborator email addresses and click “Send invite” Click Save to send invitations Note: You need an internet connection to send invitations. You'll see an error if the invitation doesn't send successfully. How do collaborators accept invitations? Collaborators will receive an email invitation and see an "Accept Invite" card in their Dashboard or Projects tab. To accept: Tap Accept Invite from the email, Dashboard, or Projects view The project will now appear in their Projects list Collaborators must accept the invitation to gain access to the project. What can collaborators do? Collaborators can: Create and upload scans to the project Rename or delete their own scans View uploaded scans from other users Collaborators cannot: Move scans to other projects Order Scan to CAD View orders Rename or delete scans from other users View scans that haven't been uploaded yet Project owners retain full access and permissions to the project. How do I manage or remove collaborators? Open the project and go to Project Info Remove the collaborator's email Click Save to apply changes Once removed, collaborators immediately lose access to the project. You can re-invite them later if needed. Who can use Invite to Capture? Project owners must be on an Essentials or Scale plan to invite collaborators. Collaborators don't need a membership. Projects they're invited to won't count toward their project limits.

Question 33

What is Scan To CAD from Twindo?

Accepted Answer

The Short Answer Twindo's Scan To CAD is a semi-automated service that converts your 3D scans into editable, design-ready, and industry-standard CAD files. These files are fully editable and designed to work with a number of different design software programs. We produce professional-grade CAD files such as: SketchUp $0.26 per square foot &#8211; Includes: 3D .skp, 3D .dwg and 3D .dae Revit $0.26 per square foot &#8211; Includes: 3D .rvt, 3D.ifc, and 3D .dwg Chief Architect $0.26 per square foot &#8211; Includes: 3D .plan, 3D .dwg, and 3D .dae 2020 Design Live $0.29 per square foot &#8211; Includes: 3D .kit, 3D .dwg, and 3D .dae Archicad $0.29 per square foot &#8211; Includes: 3D .kit, 3D .dwg, and 3D .dae Vectorworks $0.26 per square foot &#8211; Includes: 3D .kit, 3D .dwg, and 3D .dae Twindo Measurement Report Measurement Report $0.29 per square foot &#8211; Includes: .pdf and .xls 2D Drawings (PDF and AutoCAD) $0.18 per square foot &#8211; Includes: 2D .pdf, 2D .dwg, and 2D .rvt You can learn more about how Twindo's Scan To CAD pricing works in detail here: How does Scan To CAD pricing work? The Long Answer Our built-in Scan To CAD service converts the walls, floors, cabinets, countertops, fireplaces, as well as any part of the architectural shell of the space that is captured into an editable CAD file (any "movable" items like furniture and decor will not be modeled. The CAD file that is generated is intended to be a blank canvas from which you can skip all the model set-up and jump right into project-specific work. Here is a typical result for a room: The process typically works like this: You take a scan, click done and immediately on your device you'll see the scan process. Place an order for the format you need. Your scan is uploaded and moves through our semi-automated conversion pipeline, and the resulting file is emailed to you within an average of two business days (please review complete information about delivery times). The design programs we directly support are native file formats so they open right up in your program of choice. You can learn more about the programs we directly vs. indirectly support here: What file formats and programs does Scan To CAD export? Example Scan To CAD Results You can also order your scans to be merged into a global model of an entire home. For more information on capturing whole homes, please click here.

Question 34

What is the Viewer and how do I use it?

Accepted Answer

The Viewer is an easy way to view, measure, and share your scans or CAD models.. With the Viewer, you can: Virtually revisit the space Measure the scan or CAD file directly in your browser View notes and measurements created in-app Share with collaborators or clients Embed into your web page You can access the viewer directly from the app or Web. Accessing the Viewer You can access the Viewer on device by tapping a scan in the App or by clicking on a scan’s Viewer link on Twindo Web. Share You can share the Viewer with customers, contractors, subcontractors, owners, or anyone else you choose. You can share this in two ways. Invite to Capture (link). Collaborators will be able to view and add scans, photos, field notes, and PDFs. They will also be able to download any assets tied to the project, including the converted model. However, they will not be able to view order details or pricing for the project. Share individual Viewer links. In their web browser, users can view your scan and as-built, see notes, and take measurements. Two important notes: 1. If the scan hasn't been uploaded yet, you'll need to upload before sharing. 2. Sharing is off by default when just sharing individual Viewer links. Once Link Sharing is enabled, the Viewer link will be accessible to users. If you would like your scan to remain private, you can leave or toggle Link Sharing OFF. When this setting is OFF, the link to the scan is only accessible to you when you are logged in to your account. To share: tap the three dots on the top right of the scan's thumbnail to get to the scan information. Clipping Tool To make it easier to view CAD files in the Twindo Viewer. We’ve included a clipping tool that snaps to important CAD elements (ceilings, windows, doors, etc) to make viewing different floors and elements simple. Just click and drag. You can toggle the clipping tool on and off in the settings menu (gear icon) at the bottom right. Measure With the measuring tool (top right corner), click the first point then move your cursor to the second point and get an instant measurement. Zoom in by clicking and holding. Hold "Shift" key to lock measurement to X-axis, Y-axis, or Z-axis. Since measuring precise points on the 3D mesh can sometimes be difficult, we try to help speed up certain measurements. If you touch two opposing walls, the measure tool will "snap" to the straight, perpendicular distance between those two walls even if you didn't touch the exact right points. If you touch anywhere on the floor and then anywhere on the ceiling, the same thing will happen. For more complicated measurements, you can always use the normal point to point measurement feature. You can turn off "snapping" by clicking the "Planar" toggle. The second button under the ruler (the square) allows you to trace a space for a quick area calculation. Link Sharing You can change the webviewer link-sharing settings using the Twindo (formerly Canvas) app or your Twindo.com account portal. This allows you to share links with your clients and colleagues and to enable/disable access for anyone with the link as needed. To allow access to your viewer links from the Twindo App: Open the Project containing the scan you wish to share (in this example, Pat Adams) Tap "&#8230;" to open Scan Info for the scan you wish to share Toggle "link sharing" to the purple on-position Repeat this process for any additional scans, and then share the links with your colleagues! To allow link sharing using your Twindo.com web account: Log in to your web account at app.twindo.com/login, this will bring you to your Projects Menu Select the Project containing the scan you wish to share (in this example, Pat Adams) Click on the "Open Viewer" button to open the scan in the webviewer Click the Sharing icon in the bottom right corner of the webviewer, then toggle the Enable Link Sharing button to the blue on-position Repeat this process for any additional scans, and then share the links with your colleagues!

Question 35

What kind of accuracy can I expect from Twindo?

Accepted Answer

When using our Scanning Best Practices in Twindo: 3D LiDAR Measurements with your LiDAR-enabled iPad or iPhone (includes most Pro models launched since 2020), most measurements in your CAD file should be within 1-2% of what's verified manually with a tape measure, laser distance meter, or existing blueprint. You can learn more about compatible devices here: What device should I use with Twindo? For more information about our recommended capture techniques, please see our Scanning Best Practices. The accuracy of mobile 3D scanning depends a lot on the user and the environment, so unfortunately, an absolute tolerance, e.g., "all measurements ever will always be within X millimeters," can't be provided. A football field will have more absolute error than a kitchen, as will a hall of mirrors. Overall, most of our customers find that Twindo is an effective, powerful, and out-of-the-box solution for things like design, planning, pricing, estimation, sales, or documentation conditions (at the beginning of the project or as an ongoing thing). If you're looking to use Twindo for installation and construction projects that require extremely tight tolerances, you may want to verify the any critical measurements you need manually, and use the "Additional Information" button to relay these measurements to us with your order. We find that this typically still creates a large ROI, as most projects only have a few measurements that really need to be millimeter-level precise, and Twindo still automates all the other measurements and creates the 3D model. So, what can I expect in terms of hard numbers? Across the case studies we've run with professionals out in the field — using Twindo on real-world projects — we see that most measurements in the final CAD file generated are within 1-2% of what's verified manually by tape measure, laser range-finder, or existing blueprint. Some of the dimensions in my final CAD model exceed the expected variance. Why? Normally, accuracy tolerances outside of this range are simply because we received a poor scan, which in turn was because of poor scanning technique (such as moving or pivoting about without using our "fence painting" pattern), poor calibration, or other first-time user mistakes we call out in our scanning tutorial video. We always recommend scanning a few rooms around your own house to understand how Twindo handles different kinds of environments before you take it on a job site. Depending on the scan, we may need to make assumptions where the 3D sensor on your device does not directly observe the dimension in question. For example, if curtains cover a window, Twindo will typically interpret that there is indeed a window behind the curtains, but the curtains may cover the outer dimensions, so its placement within the wall may be less accurate. An even more common example is wall, floor, and ceiling thickness: Twindo does not observe these directly, so we use the scan data and construction standards to determine the dimension . A 1" difference in wall thickness accuracy could add up to be a lot more across the length of an entire building. You may also find that smaller dimensions (such as those under one foot) may have slightly wider variances than 1-2% because even being 1/16th of an inch off may be larger than 2%, and sub-inch precision is simply going to be hard to maintain consistently through the simplification process of Twindo. For example, wall thickness may come in at 4.5", but in reality, it is 4.625" — this is only a 1/8th of an inch difference, but it is a 3% error. Some kinds of environments can be a little harder to scan in general — such as a completely empty space with no furnishing and nothing on the wall (i.e., nothing for the sensor to track against), or a room with a lot of very large mirrors — and may lead to slightly wider tolerances. We recommend reading: I want to scan non-residential environments. Will Twindo work outside the home? Can Twindo scan a space that is partially built or under construction? Finally, it is important to note that humans can make mistakes too! We have debugged many orders where someone was certain that our measurements were inaccurate, but it turns out that someone had their laser range-finder against the wrong surface, or made a typo, or some other issue that had nothing to do with the scans. If you have questions or concerns about a recent Twindo order, please email support@twindo.com. What if I need better accuracy? If you need tighter tolerances than 1-2%, you can submit manually verified dimensions for key measurements, and we will "override" the scan's dimensions with your own, and you will receive a CAD model that uses the dimensions you provided us. This is a great option if you need to get a 3D model of an entire room or home, but only a few dimensions are critical. To learn more about how to submit manual dimensions with your order, please read: I need higher accuracy than 1-2%. Can I submit any measurements of my own of my own for my order?

Question 36

What should I do if there is a problem with my CAD model?

Accepted Answer

We work hard to ensure every resulting CAD file is accurate to the space scanned, but it's possible that an error might occur at some point in the process — either during your scan, or during its conversion to CAD. In the case that you find an error in your CAD model, just email support at support@twindo.com and we’ll attempt to resolve it. We can’t fix every problem, but we’ll do our best! Before emailing in, we recommend: Watch the video below to understand scanning best practices. In most cases, issues with the model are related to topics covered in this video — getting too close, rescanning areas repeatedly, scanning moving objects, etc. Ensure that you are on the latest version of the Twindo app and iOS If the above doesn't help, please contact support@twindo.com and include the Order ID as well as photos of the problematic area. If the issue is related to accuracy, please include the measurements you are specifically comparing. This will help us short-circuit a few rounds of Q&A and get your model fixed ASAP! If accuracy issues are larger than 5", supplemental scans may be needed to revise the CAD. Once a revision exceeds 5", it can affect neighboring spaces, interfering with other measurements that we took from the scan.

Question 37

What units does Twindo use, and how can I change this?

Accepted Answer

The Short Answer The Twindo app will show measurements in imperial units by default, but this can be changed in-app or through your Twindo account portal. Likewise, the default units for Twindo files (.rvt, .skp, .plan, .pls, .vwx, .kit, .dwg, or .dae) will be delivered in imperial, however, changing the units in-app or through your Account Portal will change the change the units your CAD files are delivered in. This will only change the units for future orders, so if you have an older order, or an order that is in progress, please contact support@twindo.com and we'll be happy to change those units for you. If you are importing the .obj file of the scan into another 3D program, the default scale is meters. However, different 3D programs have different conventions for how they import .obj files, so you may need to adjust the import settings and/or contact the support team for that particular software to ensure scale is maintained. The Long Answer Twindo will show measurements in imperial (feet and inches) units by default, but the in-app measurements can be easily converted to metric (meters and centimeters). Likewise, changing the units in-app or through your Twindo Account Portal will change your default CAD file units. From iPad or iPhone From Account Portal Log into your Twindo Account Portal at https://twindo.com Click "Settings" on your portal dashboard Click "Units" and select your preferred unit If you use our Scan To CAD service, AutoCAD may require you to re-scale the drawing based on your desired unit of measurement.

Question 38

Where can I watch a demo or join a webinar?

Accepted Answer

Live Twindo Demo Webinar &#8211; Register here Live webinars are held weekly. The sessions are the same, so choose one that works for you. Times are in Eastern US. Agenda: A brief introduction What you need to get started, including which devices support the Twindo app The basics of scanning How to get design-ready, editable CAD/BIM files in industry-standard formats Q&A On-demand webinars Can't wait? Watch an Introduction to Twindo now. PRO (Professional Remodeling Organization) webinar with Ted Gulyas of Clifton Design Studio The Build Show Network: Could Your Phone Replace Your Tape Measure? ASID Brand Spotlight with Jeanne and Ray Chung from Crazy Stylish Chic Webinar: Using Twindo + Archicad The Architect's Newspaper CE Strong Webinar: How to Save Hours on Measuring and Modeling Existing Conditions with Twindo, featuring architect Thomas Reynolds Click here to view the webinar on AN's CE Strong website. AIA members who watch the webinar and complete the quiz will earn one AIA LU credit.

Question 39

Why couldn't my scan be processed?

Accepted Answer

The Short Answer While very rare, we are occasionally unable to process a scan submitted through Scan To CAD. This normally relates to one of the following: A scan of an object A scan of a vehicle or boat Environment (e.g. scanning in a very dark place, or in a commercial kitchen with a lot of stainless steel) Scans that aren't of a complete room or are missing crucial information (e.g. partial scans, scans of open spaces, vehicles) Poor quality scans If a scan can not be processed, it will be “rejected” and you will not be charged for that scan. We will also contact you with more information about what happened, but in most cases, the space will need to be rescanned. The Long Answer In most cases, scans are good for Scan To CAD processing. If a scan is unable to be processed, it is likely do to one of the following common reasons: Poor Scan Quality If a scan is too messy or distorted to process, it may be rejected. This can occur for reasons such as: Re-scanning the same area over and over again Zig-zagging around the space vs. following our recommended scanning technique Fingers or other objects covering the camera Scanning too close or too far away from objects and surfaces Poor or no lighting Moving objects, people, or shadows It is very rare that a scan is so poor it can’t be processed at all, but it does happen from time to time. If you receive this rejection reason, you can always contact support@twindo.com to find out more and ways to help improve your scan quality. Partial Spaces In order to create a model and correctly charge for it, we need to know where to start and end modeling. Since models are 3D, we need boundaries to know where to start and stop in the left-right, forward-backward, and up-down directions. In 2D formats we need boundaries left-right, and forward-backward. If we're unable to determine some kind of boundary such as a wall, window, door, etc., your order may be rejected. Non-Room Scans While Scan To CAD does process and includes many architectural details, it is not designed to process and convert objects into CAD files. Scans of objects (e.g., furniture, people, vehicles) will be rejected. We encourage you to reach out to support@twindo.com if you’re unsure. Non-structural spaces may occasionally be rejected if they require a high level of manual human attention and QA. You can read more on this here: I want to scan non-residential environments. Will Twindo work outside of the home?

Don’t see an answer? Ask us.
